Pressure devices are available in cooperation with the responsible members of LNS.

Before writing a proposal involving pressure, please check the feasibility both with the instrument scientist, and the relevant person responsible for the pressure cell:

  • J. White: clamp cells - single crystal inelastic and elastic neutron scattering, Paris-Edinburgh Press - powder samples, single crystals in optimal circumstances.
  • D. Sheptiakov: clamp cells - powder neutron diffraction.

NameDescriptionRangeUsed inDim
P9? clamp cell for elastic ns <9 kbarILL2, ILL5d=7, c=20
P15clamp cell for elastic ns <15 kbarILL2, ILL5d=7, c=20
P10clamp cell for inelastic ns<10 kbarILL2, ILL5d=7, c=20
P18?clamp cell for inelastic ns<18 kbarILL5 d=7, c=20
P30?single crystal clamp cell for elastic ns<30 kbarAPD d=4, c=8
PE Paris-Edinburgh press (opposed anvils)<100 kbarRT d=5, c=1.5

d: sample space diameter
c: useable sample height

Attachments:  Pcells_at_SINQ_PSI_Oct_2016.pdf  12kbar_Cell_PSI.png  12kbar Cell PSI.png
